Compact structure design with easy operation and cleaning properties.
Variable speed adjustable according to requirement. Excellent grinding effect. Suitable for continuous small batch production.
Model
Motor
Powder
(HP/Kw)
Grinding
Chamber
(Volume, L)
Production
Volume
(L/H)
Cooling Water
Consumption
(L/H)
Weight
(kg)
Dimension
L/W/H
(mm)
S-1.4
3/2.2
1.4
1 - 50
250 - 400
125
840/610/580
* Data Provided for reference purpose only, company reserve the right to change or modify any particular without prior notice.
